SUPERIOR METAL FABRICATION CAPACITIES IN HAMILTON
At Grizzly Custom Fabrication in Hamilton, our metal fabrication capacities are second to none. With our variety of specialized equipment, skilled craftsmen, and a commitment to excellence, we can handle a wide range of metal fabrication projects with precision and efficiency. Our team has the expertise to deliver superior results that meet industry standards. From small-scale components to large-scale structures, call Grizzly Custom Fabrication for all your metal fabrication needs in Hamilton and surrounding areas.
MAIN CAPABILITIES/CAPACITIES
Our capacities include:
Hi-Def CNC Plasma Cutting & Marking Up To 3” MS Plate
-
table holds (2) 5” x 10’ or (1) large sheet to 11’ x 12’
Shearing
-
10’ wide x wms
-
10” wide x 1/4” ss
4 Roll CNC Plate Rolls
-
3/8” x 98” (Thicker materials at shorter lengths can be rolled)
-
1/4’ x 80”
Ironworker 125 ton
-
Punching, shearing, coping
Pipe Bending
-
up to 3” O.D.
Flanging/End Treatment/Bed Rolling
.
Horizontal Boring Mill
.
Line Boring with Automated Welding
-
up to 30” diameter
-
Using york line bore equipment
Break Forming
-
12’ x 350 ton 5-axis CNC with extensive tooling
CNC Horizontal Bending
-
40 tons
Profile Rolling
-
up to 5” section modulus
-
Able to roll 5” x 5” x 1/2” Angle
-
5” x 1” bar the hard way 2 different machines
-
5” section modulus & 3” section modulus *most die
Radial Drilling
-
up to 2.5”
Saw Cutting (Automated & Conventional)
-
14” h. X 18” w. up to 40’ (24’ or less preferred)
Sheet Metal Coping
-
9”x 9”x 5/32’
Laser Welding
.
All Types of Welding
-
(MS, SS, AL & exotics)
-
up to 650 amps mig
-
360 amps tig or stick
-
Can perform any required procedure
OTHER SERVICES AVAILABLE
-
Conventional Machining Mill & Lathe
-
Powder Coating
-
Hot Dip Galvanizing
-
Hardening
-
Nitriding
SOME OF THE TYPES OF FABRICATING WE DO AT GRIZZLY CUSTOM FABRICATION
Ladders
Hoppers/funnels
Custom Design – 3D Modelling – Custom Machining
Structural Steel
Security Fencing
Fleet Vehicle Upfitting
Mezzanines
Custom Signage
Hydraulic Lines
Stainless Steel Countertops
Custom Trailer Design & Fabrication
Railings
METAL FABRICATION GALLERY
Check our latest work:
